<div class="detailmodule_dynamic"><kse:widget data-widget-type="customText" id="1005000000567623" type="relation"></kse:widget></div><div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div><br/>Features:<br/>1.The product is made of high quality material, long service life, quality assurance<br/>2. The product has a memory function, the data will not be lost when the power is switched off<br/>3. 4-bit digital display, display range 0-9999<br/>4. Low level effective, wide voltage work, support DC4-40V <br/>5. With cumulative +1, clear zero, power failure data memory function<br/>6. Two digital tube colours are available: blue and red.</div><div><br/></div><p>Parameter:<br/>Product Name: Counter Module<br/>Operating voltage: DC4-40V (recommended for use under 5-35V)<br/>Current: 30mA (under 12V)<br/>Input: counting (+1), clear, low level active<br/>Digital tube specifications: 0.56 inches<br/>Digital tube: 4 digits<br/>Digital tube display colour: red/blue<br/>Counting range: 0-9999<br/>Counting speed: 0-200Hz (i.e. up to 200 times per second)</p><p>Notes:<br/>1. The external sensor must be NPN normally open type.<br/>2. The positive pole of the module is connected to the positive pole of the power cord, and the negative pole is connected to the negative pole of the power cord.</p><p>Package include: <br/>Counter Module X1<br/></p></div></div><p><br/></p>
