<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p> <span><span style="background-color:#E53333;">The United States customers attention:</span><br /> When you select "Ship From United States", the following addresses will not provide delivery service:<span style="color:#E53333;"> Hawaii, Alaska, Puerto Rico, Guam, APO, DPO, FPO</span>, etc. Recommend you to choose "Ship From China".Thank you！！！<br /> <span style="background-color:#E53333;">Clientes de España atención</span>:<br /> Cuando selecciona "Enviar desde España", el servicio de entrega no está disponible en los siguientes códigos postales:<br /> <span style="background-color:#E53333;">35000-35999</span><br /> <span style="background-color:#E53333;">38000-38999</span><br /> Se recomienda que elija "Enviar desde China". ¡Gracias! ! !<br /> <br /> </span> <table class="ke-zeroborder" width="100%" cellspacing="0" cellpadding="0" border="0"> <tbody> <tr> <td> <div> <div> <p class="MsoNormal"> <div style="font-size: 28px; font-family: tahoma, geneva, sans-serif; font-weight: bold; padding: 2px 2px;"> </div></div> <div class="detailmodule_dynamic"><kse:widget data-widget-type="customText" id="1005000004871237" title="" type="custom"></kse:widget></div> <div class="detailmodule_html"><div class="detail-desc-decorate-richtext"> </div> </p> </div> </div> <div style="padding:15px;border:solid 1px #aeaeae;"> <p> <span style="color:black;font-family:inherit;font-size:12px;">CD74HC4067 Analog Multiplexer Selector Module Mutual Convert Analog Digital MUX Breakout Board CMOS Precise 16-Channel for Electronic Components<br /> <strong>Features:</strong><br /> <strong>1.Versatile:</strong> This analog digital multiplexer features the highly useful CD74HC4067, a high-speed CMOS analog multiplexer/demultiplexer with 16 channels. It acts like a rotary switch, internally routing the common pin (SIG) to one of the 16 channel pins (CHANxx).<br /> <strong>2.Optimal Performance:</strong> This breakout board module is designed to handle both digital and analog signals, making it versatile for various applications. However, please ensure that the voltage of the signals does not exceed the specified limit (VDC) to maintain optimal performance.<br /> <strong>3.Bi-Directional Operation:</strong> The analog multiplexer selector module can be controlled by connecting 4 digital outputs to the designated chip address pins (S0-S3). By sending the binary address of the desired channel (refer to the datasheet), you can easily select and route signals. This feature allows you to connect up to 16 sensors to your system using only 5 pins.<br /> <strong>4.Compatible:</strong> Apart from analog and digital signals, this analog digital&nbsp;MUX&nbsp;breakout board also supports the transmission of TTL-level serial data between multiple devices. You can use it to route RX (receive) and TX (transmit) lines from a microcontroller to up to 16 devices. By using multiple boards, you can create similar arrangements for I2C, SPI, and other protocols.<br /> <strong>5.Low Resistance &amp; Low Leakage:</strong> The internal switches of this analog digital multiplexer board are bidirectional, allowing bi-directional signal flow. They have low resistance, low leakage, and support voltage between ground and VDC. Additionally, the switching is designed to prevent interference. The board also features an enable pin that completely disables the common pin (all switches) when driven high, providing additional control and convenience.</span> </p><br /><br /><span style="color:black;font-family:inherit;font-size:12px;"><strong>Specification:</strong></span><br /> <span style="color:black;font-family:inherit;font-size:12px;">Origin: Mainland China</span><br /> <span style="color:black;font-family:inherit;font-size:12px;">Type: Module</span><br /> <span style="color:black;font-family:inherit;font-size:12px;">Condition: New</span><br /> <span style="color:black;font-family:inherit;font-size:12px;">Model Number: Breakout Board Module</span><br /> Analog Signal Input: C0-C15 16 Channels<br /> Analog Output: Dig<br /> Channel Control: S0-S3<br /> Size: 41*17*3mm/1.61*0.67*0.12inch<br /> 1. This is a very useful breakout board for the 16-channel analog/digital multiplexer/demultiplexer CD74HC4067.<br /> 2. The chip is like a rotary switch - it internally routes the common pin (SIG) to one of the 16 channel pins (CHANxx).<br /> 3. Suitable for both digital and analog signals (voltage cannot be higher than VDC).<br /> 4. The connection works in both directions.<br /> 5. To control it, connect the 4 digital outputs to the selected chip address pins (S0-S3).<br /> 6. and send the binary address of the channel you want (see data sheet for details).<br /> 7. This allows you to connect up to 16 sensors to your system using only 5 pins.<br /> 8. Since the multiplexer/demultiplexer also works with digital signals, you can use it to connect up to 16 sensors to your system via a pipeline.<br /> You can use it to pipe TTL-level serial data to and from multiple devices.<br /> 9. TX lines from the microcontroller to the RX lines of up to 16 devices.<br /> 10. By using multiple cards, you can create a similar arrangement for I2C, SPI, etc.<br /> 11. Internal switches are bi-directional and support voltages between ground and VDC.<br /> 12. It has low resistance, low leakage, and switches off before on to prevent interference.<br /> 13. The board also destroys the chip's enable pin, which will completely disable the common pin (all switches) when driven high.<br /> <br /> <p style="color:black;font-family:inherit;font-size:12px;"> <strong>Note:</strong><br /> Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!<br /> Please allow 1-2cm measuring deviation due to manual measurement. </p> <span style="color:black;font-family:inherit;font-size:12px;"></span><br /> <br /> </div> <br /> <div> </div> <div style="padding:15px;border:solid 1px #aeaeae;"> 1*Analog Digital Multiplexer <br /> </div> <br /> <div style="text-align:center;"> </div> <br /> <br /> <div> </div> <div style="padding:15px;border:solid 1px #aeaeae;"> <p class="MsoNormal"> <div style="font-size: 28px; font-family: tahoma, geneva, sans-serif; font-weight: bold; padding: 2px 2px;"> </div></div> <div class="detailmodule_dynamic"><kse:widget data-widget-type="relatedProduct" id="1005000003914017" title="" type="relation"></kse:widget></div> <div class="detailmodule_html"><div class="detail-desc-decorate-richtext"> </div> </p> </div> <p> </p> <p> </p> <p> </p> <p> </p> <p> <br /> </p> </td> </tr> </tbody> </table> </p></div></div>
