<div class="detailmodule_dynamic"><kse:widget data-widget-type="relatedProduct" id="1005000013403607" title="" type="relation"></kse:widget></div> <div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><br />Product selling points:<br />1.100% new quality products.<br />2. Made of high-quality materials, durable and practical.<br />3. Small size, simple application, convenient operation.<br />4. Over current, over voltage, short circuit protection<br />5. Wide range of applications.</p> <p>Product parameters:<br />Input voltage: 8-60V<br />Input current: 20A<br />Quiescent current: 15mA (12V output 20V, the higher the output voltage, the more the current will be calm)<br />Output voltage: 12-80V continuously adjustable<br />Output current: 20A MAX, more than 15A, please enhance the heat dissipation (input, output pressure related, the greater the pressure output current is smaller)<br />Constant range: 0.5-20A<br />Output power: input voltage * 20A, such as: input 12V * 20A = 240W, input 24V * 20A = 480W input 36V * 20A = 720W, input 48V * 20A = 960W, input 60V * 20A = 1200W<br />Working temperature: -40 ~ + 85 degrees (the ambient temperature is too high, please strengthen the heat dissipation)<br />Operating frequency: 150KHz<br />Conversion efficiency: up to 95%<br />Module size: 116&times;52&times;15mm</p> <p>Packing list: <br />Power module *1<br /></p></div></div>
