1pc DC-DC Converter 15A 400W Step up Step down Buck Boost Notebook charging module
<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p><span style="font-size: 19px; font-family: Tahoma;">Feaures: </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Module name :400W boost constant current module </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Module properties: non-isolated step-up module (BOOST) </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Input voltage: DC8.5V-50V </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Input current: 15A (MAX) exceeds 8A please enhance heat dissipation </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Quiescent current: 10mA (12V liter 20V, the output voltage, the higher the current will increase too quiet) </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Output voltage: 10-60V continuously adjustable </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Constant] range: 0.2-12A </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Temperature: -40 to + 85 degrees (ambient temperature is too high, please enhance heat dissipation) </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Operating frequency: 150KHz </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Conversion efficiency: up to 96% </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Overcurrent protection: yes </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Input reverse polarity protection: no </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Installation: 4pcs 2.55mm screw holes </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Connection method: Connection Output </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Module size: 67mm X48mm X 28mm (LxWxH) </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Single module: 60g </span></p><p><br></p><p><span style="font-size: 19px; font-family: Tahoma;">Package Include: 1 x 400W Boost Converter </span></p></div></div>
<div class="detailmodule_image"></div>
$6.74
$5.075
- Category : Home Improvement
- Brand : nanjing_life_store Nanjing life Store
Colors
Sizes
-
+
<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p><span style="font-size: 19px; font-family: Tahoma;">Feaures: </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Module name :400W boost constant current module </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Module properties: non-isolated step-up module (BOOST) </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Input voltage: DC8.5V-50V </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Input current: 15A (MAX) exceeds 8A please enhance heat dissipation </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Quiescent current: 10mA (12V liter 20V, the output voltage, the higher the current will increase too quiet) </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Output voltage: 10-60V continuously adjustable </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Constant] range: 0.2-12A </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Temperature: -40 to + 85 degrees (ambient temperature is too high, please enhance heat dissipation) </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Operating frequency: 150KHz </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Conversion efficiency: up to 96% </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Overcurrent protection: yes </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Input reverse polarity protection: no </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Installation: 4pcs 2.55mm screw holes </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Connection method: Connection Output </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Module size: 67mm X48mm X 28mm (LxWxH) </span></p><p><span style="font-size: 19px; font-family: Tahoma;">Single module: 60g </span></p><p><br></p><p><span style="font-size: 19px; font-family: Tahoma;">Package Include: 1 x 400W Boost Converter </span></p></div></div>
<div class="detailmodule_image"></div>
