<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p><span style="font-size:16px;font-family:Verdana">Specification</span></p><p><span style="font-size:16px;font-family:Verdana">Red - VCC: Positive terminal of the power supply</span></p><p><span style="font-size:16px;font-family:Verdana">Black - GND: Negative terminal of the power supply</span></p><p><span style="font-size:16px;font-family:Verdana">Yellow - SCL: IIC Clock</span></p><p><span style="font-size:16px;font-family:Verdana">Green - VCC: IIC data</span></p><p><span style="font-size:16px;font-family:Verdana">Measurement range:</span></p><p><span style="font-size:16px;font-family:Verdana">Temperature: -40 to 125℃, Humidity: 0 to 100%RH</span></p><p><span style="font-size:16px;font-family:Verdana">Output interface: Standard I2C protocol</span></p><p><span style="font-size:16px;font-family:Verdana">Cable length: 1/2/3 meters </span></p><p><span style="font-size:16px;font-family:Verdana">Materials: Metal, Plastic</span></p><p><span style="font-size:16px;font-family:Verdana">Sensor model: SHT20</span></p><p><span style="font-size:16px;font-family:Verdana">Power supply voltage: 2.1 - 3.6V. Do not use 5V power supply.</span></p><p><span style="font-size:16px;font-family:Verdana">Measurement accuracy:</span></p><p><span style="font-size:16px;font-family:Verdana">Temperature: &plusmn;0.3℃ (5 - 60℃), Humidity: &plusmn;3%RH (20 - 80%RH)</span></p><p><span style="font-size:16px;font-family:Verdana">Response time: 8 seconds (tau63%)</span></p><p><span style="font-size:16px;font-family:Verdana">Power consumption: 3.2μW (8-bit, 1 measurement/second condition)</span></p><p><span style="font-size:16px;font-family:Verdana">Long-term drift: Temperature: &lt; 0.04℃ per year, Humidity: &lt; 0.5% RH per year</span></p><p><span style="font-size:16px;font-family:Verdana">Sensor model: SHT30</span></p><p><span style="font-size:16px;font-family:Verdana">Supply voltage: 2.15 - 5.5V</span></p><p><span style="font-size:16px;font-family:Verdana">Measurement accuracy:</span></p><p><span style="font-size:16px;font-family:Verdana">Temperature: &plusmn;0.2℃ (0 - 65℃), Humidity: &plusmn;2%RH (10 - 90%RH)</span></p><p><span style="font-size:16px;font-family:Verdana">Response time: 8 seconds (tau63%)</span></p><p><span style="font-size:16px;font-family:Verdana">Power consumption: 4.8μW (low repeatability at 2.4V, 1 time/second)</span></p><p><span style="font-size:16px;font-family:Verdana">Long-term drift:</span></p><p><span style="font-size:16px;font-family:Verdana">Temperature: &lt;0.03℃/year, Humidity: &lt;0.25%RH/ year </span></p><p><span style="font-size:16px;font-family:Verdana">Sensor model: SHT40</span></p><p><span style="font-size:16px;font-family:Verdana">Power supply voltage: 1.08 - 3.6V. Do not use 5V power supply.</span></p><p><span style="font-size:16px;font-family:Verdana">Measurement accuracy:</span></p><p><span style="font-size:16px;font-family:Verdana">Temperature: &plusmn;0.2℃ (0 - 65℃), Humidity: &plusmn;1.8%RH (30 - 70%RH, @25&deg;C)</span></p><p><span style="font-size:16px;font-family:Verdana">Response time: 6 seconds (tau63%)</span></p><p><span style="font-size:16px;font-family:Verdana">Power consumption: 0.5μW (low repeatability at 1.2V, 1 time/second)</span></p><p><span style="font-size:16px;font-family:Verdana">Long-term drift:</span></p><p><span style="font-size:16px;font-family:Verdana">Temperature: &lt;0.03℃/year, Humidity: &lt;0.2%RH/ year</span></p><p><span style="font-size:16px;font-family:Verdana">Features:</span></p><p><span style="font-size:16px;font-family:Verdana">Using 304 stainless steel and waterproof adhesive. Its characteristics include excellent impact resistance, heat resistance, low temperature resistance, chemical resistance, electrical performance, stable product size, and good surface gloss</span></p><p><span style="font-size:16px;font-family:Verdana">4P terminal connection wire.</span></p><p><span style="font-size:16px;font-family:Verdana">Note:</span></p><p><span style="font-size:16px;font-family:Verdana">1. The color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. Please refer to the actual product received.</span></p><p><span style="font-size:16px;font-family:Verdana">2. Please allow slight manual measurement deviation for the data.</span></p><div class="detailmodule_image"> </div><br /></div></div>
