<div class="detailmodule_dynamic"><kse:widget data-widget-type="customText" id="1005000004074434" type="relation"></kse:widget></div><div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div><br/>Features: <br/>1. Made of high-quality materials, durable and equipped with a color screen and digital tube display. <br/>2. Support radio function and multiple music formats, such as MP3/WMA/WAV/FLAC/APE lossless music. <br/>3. Supports BT function, BT version 5.0, supports infrared remote control operation at a distance of 5-10 meters. <br/>4. The power amplifier is 2 * 25W and can be connected to two 25W speakers. <br/>5. Supports MP3/USB/TF/LINE IN/FM/BT/remote control function, with a wide range of applications.</div><div><br/></div><p>Parameter: <br/>Main control IC: AB5362B <br/>BT IC: AB5362B <br/>BT version: 5.0 <br/>Power amplifier: HT360 <br/>Power supply: DC 12V (range 7V-15V) <br/>Power: 2 * 25W <br/>BT call function <br/>Recording function <br/>Folder switching function <br/>Music formats: MP3/WMA/WAV/FLAC/APE lossless music <br/>Radio FM frequency: 87.5-107.5 MHz <br/>Support Function Introduction: Supports MP3/USB/TF/LINE IN/FM/BT/Remote Control/DC 12V (Range 7V-15V) <br/>Panel size: 108 length * 25 width, with screw hole positions on both sides of the panel. The depth of the panel is 32MM <br/>Main functions: <br/>1. Dual decoding supports music in MP3/WMA/WAV/FLAC/APE lossless formats; <br/>2. Supports BT function, BT version 5.0; <br/>3. Supports BT calling function; <br/>4. Support recording function; <br/>5. Function 2 * 25W, and can connect two 25W speakers at the same time; <br/>6. Support folder switching; <br/>7. Digital tube display with color screen; <br/>8. Support USB interface (USB flash drive); <br/>9. Power outage memory function; <br/>10. Support infrared remote control operation at a distance of 5-10 meters; <br/>11. Support external audio input LINE IN; <br/>12. Supports FM radio and retrieval frequency range (87.5MHz to 108.0MHz); <br/>13. Key: Four button multi-directional control, VOL -/SCAN/VOL+/MODE; <br/><br/>Key operation details: <br/>1. VOL button (previous song/volume decrease): In MP3 mode, VOL - short press to previous song, long press to volume decrease; Short press in FM mode to increase the station number by one; Short press to indicate the previous song in BT function, long press to indicate a decrease in volume; Double click to switch to the previous folder. <br/>2. SCAN button (play/pause): Press AUTO briefly in MP3 mode to play/pause; Short press in FM mode for automatic collection and coexistence of stations, long press without function; Short press to play/pause in BT function. <br/>3. VOL+button (next song/volume increase): In MP3 mode, VOL+short press to next song, long press to increase volume; Short press in FM mode to lower the station number by one; Short press to select the next BT song under BT function, and long press to select the volume to decrease; Double click to switch to the next folder. <br/>4. MODE button: Switch between USB/TF/FM/LINE IN/BT functions in sequence; Long press is the recording function, press the button again to cancel the recording function and play the recording file; When recording, it is necessary to connect a storage device, such as a USB flash drive or TF card; <br/>Recording function description: <br/>When recording, it is more necessary to connect a storage device, such as a USB flash drive or TF card</p><p>Package include: <br/>1X decoding board <br/>1X remote control <br/>4X connection line<br/></p></div></div><p><br/></p>
