<div class="detailmodule_dynamic"><kse:widget data-widget-type="customText" id="1005000004384065" type="relation"></kse:widget></div><div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div><br/>Features:<br/>1. Small volume, high power, high efficiency, complete protocols, mainstream open protocols are basically supported.<br/>2.Module for 3.7V lithium batteries, including polymer, 18650, 21700 lithium batteries. Ensure that the battery is not aging, the battery can be connected in parallel and not in series.<br/>3. Module size is relatively small, the heat dissipation area is limited, high-power output heat is a normal phenomenon.<br/>4. With automatic load detection / light load detection, support for digital display and LED light power indication.<br/>5. With output overcurrent/short circuit protection, charging timeout/overvoltage protection.</div><br/><p>Parameter:<br/>Charging current up to 5A with 96% efficiency<br/>Output power up to 22.5W with 95% efficiency<br/>Support VOOC, DASH, Warp<br/>Support PPS/PD3.0/PD2.0<br/>Support QC4+/QC4/QC3.0/QC2.0<br/>Support FCP, SCP (5V4.5A or 4.5V/5A)<br/>Support FCP, SCP, HSCP<br/>Support SFCP<br/>Battery charging support PD3.0/PD2.0, AFCFCP, SCP , PE1.1</p><p>Module Input Interface<br/>Buttons: When short press action, open the USB port and the lightly loaded Type-C output port for external discharge and power display. When double-click action, close the USB port and Type-C output port and power display; if external power supply exists, only the output port will be closed.<br/>Type-C port: support input and output.<br/>USB port: high current output interface.<br/>B+: positive battery interface, use must be soldered, the wire must be thick and not too long.</p><p>Package include:<br/>Fast charging module*1<br/></p></div></div><br/>
