433MHz Universal Wireless Remote Control Switch DC 12V 4CH Relay Wireless RF Remote Control Switch for Lights Garage Door Motor
<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p>Features:<br/><br/>1. Jog function:<br/>Press the code pairing button on the control board once, and the LED indicator flashes once. After the LED indicator lights up, press the remote control button that needs to be paired, and the LED indicator on the control panel flashes 3 times in succession.<br/><br/>2. Self-locking function:<br/>Press the code pairing button on the control panel twice in a row, the LED indicator flashes 2 times, and when the LED indicator lights up, press the button on the remote control that needs to be paired, and the LED indicator on the control panel flashes 3 times in succession.<br/><br/><br/>Parameters:<br/><br/>1. Input voltage: DC 12V<br/><br/>2. Receiving frequency: 433MHz, 315MHz<br/><br/>3. Receiving sensitivity: -108dbm<br/><br/>4. Quiescent current: 5mA<br/><br/><br/>Description of receiving terminal:<br/><br/>+V—Power "positive" input<br/><br/>GND—power supply "negative" input<br/><br/>1—KC1 relay "normally closed" terminal<br/><br/>2—KC1 relay "common" terminal<br/><br/>3—KC1 relay "normally open" terminal<br/><br/>4—KC3 relay "normally closed" terminal<br/><br/>5—KC3 relay "common" terminal<br/><br/>6—KC3 relay "normally open" terminal<br/><br/>7—KC2 relay "normally closed" terminal<br/><br/>8—KC2 relay "common" terminal<br/><br/>9—KC2 relay "normally open" terminal<br/><br/>10—KC4 relay "normally closed" terminal<br/><br/>11—KC4 relay "common" terminal<br/><br/>12—KC4 relay "normally open" terminal<br/><br/><br/>Package includes:<br/><br/>Type A: 12V 433MHz 4-way with shell*1+mahogany 4-key ABCD*1*1<br/><br/>Type B: 12V 433MHz 4-way with shell*1+red d4 key ABCD*1*1<br/><br/>Type C: 12V 433MHz 4-way with shell*1+metal 4-key ABCD*1*1<br/><br/>Type D: 12V 315MHz 4-way with shell*1+mahogany 4-key ABCD*1*1<br/><br/>Type E: 12V 315MHz 4-way with shell*1+red d4 key ABCD*1*1<br/><br/>Type F: 12V 315MHz 4-way with shell*1+metal 4-key ABCD*1*1<br/><br/>Type G: 12V 315MHz 4-way 4-way intelligent wireless control module relay with shell*1<br/><br/>Type H: 12V 413MHz 4-way 4-way intelligent wireless control module relay with shell*1</p></div></div><p><br/></p>
$9.5
$6.35
- Category : Home Improvement
- Brand : z_industry_store Z Industry Store
Colors
Sizes
-
+
<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p>Features:<br/><br/>1. Jog function:<br/>Press the code pairing button on the control board once, and the LED indicator flashes once. After the LED indicator lights up, press the remote control button that needs to be paired, and the LED indicator on the control panel flashes 3 times in succession.<br/><br/>2. Self-locking function:<br/>Press the code pairing button on the control panel twice in a row, the LED indicator flashes 2 times, and when the LED indicator lights up, press the button on the remote control that needs to be paired, and the LED indicator on the control panel flashes 3 times in succession.<br/><br/><br/>Parameters:<br/><br/>1. Input voltage: DC 12V<br/><br/>2. Receiving frequency: 433MHz, 315MHz<br/><br/>3. Receiving sensitivity: -108dbm<br/><br/>4. Quiescent current: 5mA<br/><br/><br/>Description of receiving terminal:<br/><br/>+V—Power "positive" input<br/><br/>GND—power supply "negative" input<br/><br/>1—KC1 relay "normally closed" terminal<br/><br/>2—KC1 relay "common" terminal<br/><br/>3—KC1 relay "normally open" terminal<br/><br/>4—KC3 relay "normally closed" terminal<br/><br/>5—KC3 relay "common" terminal<br/><br/>6—KC3 relay "normally open" terminal<br/><br/>7—KC2 relay "normally closed" terminal<br/><br/>8—KC2 relay "common" terminal<br/><br/>9—KC2 relay "normally open" terminal<br/><br/>10—KC4 relay "normally closed" terminal<br/><br/>11—KC4 relay "common" terminal<br/><br/>12—KC4 relay "normally open" terminal<br/><br/><br/>Package includes:<br/><br/>Type A: 12V 433MHz 4-way with shell*1+mahogany 4-key ABCD*1*1<br/><br/>Type B: 12V 433MHz 4-way with shell*1+red d4 key ABCD*1*1<br/><br/>Type C: 12V 433MHz 4-way with shell*1+metal 4-key ABCD*1*1<br/><br/>Type D: 12V 315MHz 4-way with shell*1+mahogany 4-key ABCD*1*1<br/><br/>Type E: 12V 315MHz 4-way with shell*1+red d4 key ABCD*1*1<br/><br/>Type F: 12V 315MHz 4-way with shell*1+metal 4-key ABCD*1*1<br/><br/>Type G: 12V 315MHz 4-way 4-way intelligent wireless control module relay with shell*1<br/><br/>Type H: 12V 413MHz 4-way 4-way intelligent wireless control module relay with shell*1</p></div></div><p><br/></p>
