<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div style="margin:10px auto 0px;margin-bottom:0px;margin-top:10px;margin-left:auto;margin-right:auto;display:inline-block;max-width:100%"> <div> </div> <div style="margin-top:-47.64%"> <div style="margin-top:0%;margin-left:0%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006132617938.html" target="_blank" class=""></a> </div> <div style="margin-top:-23.82%;margin-left:20%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006147225775.html" target="_blank" class=""></a> </div> <div style="margin-top:-23.82%;margin-left:40%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006169414881.html" target="_blank" class=""></a> </div> <div style="margin-top:-23.82%;margin-left:60%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006182524535.html" target="_blank" class=""></a> </div> <div style="margin-top:-23.82%;margin-left:80%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006290016278.html" target="_blank" class=""></a> </div> <div style="margin-top:0%;margin-left:0%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006098530526.html" target="_blank" class=""></a> </div> <div style="margin-top:-23.82%;margin-left:20%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006113057032.html" target="_blank" class=""></a> </div> <div style="margin-top:-23.82%;margin-left:40%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006119782014.html" target="_blank" class=""></a> </div> <div style="margin-top:-23.82%;margin-left:60%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006113027575.html" target="_blank" class=""></a> </div> <div style="margin-top:-23.82%;margin-left:80%;width:20%"> <a href="http://www.aliexpress.com/item/detail/1005006296809813.html" target="_blank" class=""></a> </div> </div> </div><hr /><p><span style="font-size:22px"><strong>YIDI 5/10/20 pcs BP Stop Plugs BSP R 1/2 3/8 1/4 1/8 Air Hose Fitting Pneumatic Screw Thread Connection Connector R1/2 R3/8 R1/4 R1/8</strong></span><br /><br /><strong><span style="font-size:18px">Specification:</span></strong><br />Item No.: BD<br />Connection Way: Threaded&nbsp;Connection<br />Type: Male Thread<br />Design: Straight<br />Material: Metal<br />Fluid Type: Clean Air, Vacuum, No Toxic Gas<br />Normal Operating Pressure: 0~10kgf/cm&sup2; (0~1.0MPa / 0~1.0bar)<br />Max.Operating Pressure: 15.0 bar(1.5MPa)<br />Negative Pressure: &nbsp;-750mmhg (10Torr)<br />Ambient And Fluid Temperature: 0~60℃ (140℉)</p><div style="text-align:left" align="left"> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <br /> <span style="font-size:18px"><strong>Installation Instructions:</strong></span> </div><table style="border-collapse:collapse;width:100%;text-align:left" border="1" cellpadding="0" cellspacing="0" align="left"></table><table style="border-collapse:collapse;width:944px" border="0" cellpadding="1" cellspacing="1"> <tbody> <tr> <td style="width:236px"><p style="text-align:left;margin:0px;margin-bottom:0px;margin-top:0px;margin-left:0px;margin-right:0px" align="left"></p></td> <td style="width:235px"> <div> <strong>Installation</strong> </div> <div> Grasp the tubing and slowly push it into the fitting until it comes to stop. The tubing will be locked by the spring gasket. </div></td> <td><p style="text-align:left;margin:0px;margin-bottom:0px;margin-top:0px;margin-left:0px;margin-right:0px" align="left"></p></td> <td style="width:235px"> <div> <strong>Remove</strong> </div> <div> Push the release button to open the spring gasket so that the tubing can be released. </div></td> </tr> <tr> <td colspan="4"><p><span style="font-size:14px"><strong>Cautions:</strong></span><br /><strong>1. Cleaning</strong>: Clean the piping before connection to remove debris.<br /><strong>2. Tubing Cut</strong>: Ensure a perpendicular cut without scratches on the tubing's outer diameter.<br /><strong>3. Pipe Length</strong>: Avoid excessive bending; select a proper pipe length.<br /><strong>4. Connection</strong>: After connecting, pull the tubing gently to check its seal.<br /><strong>5. Release</strong>: Push evenly on the release button flange for proper tubing withdrawal.<br /><strong>6. Removal</strong>: Avoid rotating the tubing fully during removal.<br /><strong>7. Assembly</strong>: Ensure no debris enters when screwing pipes and fittings together.</p></td> </tr> <tr> <td colspan="4"><p><strong>Safety Instructions:</strong><br /></p></td> </tr> <tr> <td colspan="4"><p><strong>1. Pressure</strong>: Ensure zero pressure in the tubing before removal.<br /><strong>2.&nbsp;Spatter Zones</strong>: Avoid standard fittings in spatter-producing areas.<br /><strong>3.&nbsp;Monitor Conditions</strong>: Stay within specified pressure and temperature ranges.<br /><strong>4.&nbsp;Environment</strong>: Avoid corrosive gases, chemicals, and extreme conditions.<br /><strong>5.&nbsp;Placement</strong>: Avoid areas with heavy vibrations or shocks.<br /><strong>6. Direction</strong>: Install tubing in the correct one-way direction.</p></td> </tr> </tbody> </table><div> <strong><span style="font-size:18px"><span style="font-family:Arial, Helvetica, sans-serif"><br />Dimension:</span></span></strong> <br /> </div><div> <div> <kse:widget data-widget-type="customText" id="1005000008766803" type="custom"></kse:widget> </div> <div> <kse:widget data-widget-type="customText" id="1005000000792466" type="custom"></kse:widget> </div> <div> <kse:widget data-widget-type="customText" id="1005000000792470" type="custom"></kse:widget> </div> </div><br /></div></div>
