<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div style="font-size: 28px; font-family: tahoma, geneva, sans-serif; font-weight: bold; padding: 2px 2px;"> <kse:widget data-widget-type="customText" id="1005000000642004" title="828 Code" type="custom"></kse:widget> </div><p> <span style="background-color:#FFFFFF;font-size:18px;"><strong>U.S. buyer attention:<br /> The areas where the US warehouse does not deliver goods are: Hawaii, Alaska, Puerto Rico, Guam and other US overseas territories. And the military address.<span style="background-color:#FFFFFF;font-size:18px;"><strong> But you can choose ship from China.</strong></span><br /> <br /> Spanish buyers attention:<br /> If your address includes following postal code please do not choose the Spanish warehouse.<br /> The zip code starts with 35/38<br /> Overseas warehouse cannot be delivered. But you can choose ship from China </strong></span> </p> <p> <span style="background-color:#FFFFFF;font-size:18px;"><strong></strong></span><span style="background-color:#E53333;"></span> </p> <p> </p> <table class="ke-zeroborder" width="100%" cellspacing="0" cellpadding="0" border="0"> <tbody> <tr> <td> <div> <span><br /> </span> </div> <span><br /> </span> <div style="padding:15px;border:1px solid #AEAEAE;"> <span> <span style="color:black;font-family:inherit;font-size:12px;">5W UsDX All Mode HF Transceiver QCX-SSB To SSB 3-Band SDR QRP HF Transceiver W/ DSP SDR High Frequency Transceiver with Handheld Microphone<br /> </span><strong>Feature:</strong><br /> <strong>1. IRF Series Transmitter Tubes: </strong>The SDR QRP transceiver utilizes IRF series transmitter tubes for long-lasting performance and reliability, ensuring consistent communication in various conditions.<br /> <strong>2. BNC Antenna Connector: </strong>Easily connect your antenna using the BNC connector, making this all mode HF transceiver versatile and user-friendly for both novice and experienced operators.<br /> <strong>3. Three Frequency Bands: </strong>This SDR QRP HF transceiver supports three frequency bands, providing flexibility and wide coverage for your communication needs, making it an essential tool for any radio enthusiast.<br /> <strong>4. Digital Power and SWR Display:</strong> Featuring a digital display for power and standing wave ratio (SWR), this all mode transceiver ensures precise monitoring and adjustment, enhancing your operating experience.<br /> <strong>5. FT8 Option Connector and Marking:</strong> The high frequency transceiver includes a connector for the FT8 option and marking for durability and clear labeling, making it a top choice for serious operators.<br /> <br /> <br /> <br /> <span><strong>Specification:</strong></span><br /> <span>Origin: Mainland China</span><br /> <span>DIY Supplies: ELECTRICAL</span><br /> USDX software open source:<br /> /&gt; Some hardware open source websites:<br /> /&gt; /&gt; /&gt; Group:<br /> /&gt; Description:<br /> This is a shortwave QRP SSB/CW transceiver. It has a 1602 screen, built-in microphone, built-in speaker! It can be connected to an autokey and can decode via CW<br /> <br /> Feature list:<br /> Simple, fun and versatile QRP SSB HF transceiver with embedded DSP and SDR capabilities.<br /> EER Class E drives the SSB transmit stage.<br /> 12V power supply provides about 5W maximum PEP SSB output.<br /> Full mode support: USB, LSB, CW, AM, FM.<br /> DSP filters: 4000, 2500, 1700, 500, 200, 100, 50Hz passband.<br /> DSP functions: automatic gain control (AGC), noise reduction (NR), voice trigger, voice trigger Xmit (VOX), RX attenuator attenuator (ATT), TX noise gate, TX driver control, volume control, dBm/S meter.<br /> SSB reverse sideband/carrier suppression transmission: better than -45dBc, IMD3 (two-tone) -33dBc, reception: better than -50dBc.<br /> Supports multiple bands, continuously adjustable within the 160m-10m band (performance loss from 20kHz to 99MHz).<br /> Open source firmware, built-in Arduino IDE; allows experimentation, new features can be added, contributions can be shared through Github, software complexity: 2000 lines of code.<br /> Software-based VOX can be used as fast full-intrusive (QSK and semi-QSK operation), or auxiliary to operate in digital mode (no CAT or PTT interface) for RX/TX switching, external PTT output with TX/PA control delay.<br /> Simple installation modification by replacing only 8 components and 8 wires.<br /> &nbsp;Lightweight, low-cost transceiver: thanks to the EER transmitter E-level, it has high power efficiency (no bulky heat sink required) and simple design (no complex balanced linear power amplifier required).<br /> SSB transmitter stage is completely digital and software-based: samples the microphone input and reconstructs the SSB signal by controlling the phase of the SI5351 PLL (via I2C with small frequency changes above 800kbit/s) and the amplitude of the PA (via PWM of the PA key shaping circuit).<br /> Fully digital and software-based SDR receiver stage (optional): samples the I/Q (complex) signal from the quadrature sampling detector digital mixer and performs a 90 degree phase shift (Hilber transform) in software and eliminates one phase shift by adding a sideband.<br /> Three independent switchable analog front-end receiver attenuators (0dB, -13dB, -20dB, -33dB, -53dB, -60dB, -73dB).<br /> Receiver Noise Level MDS: -135 dBm at 28MHz (200Hz BW).<br /> Receiver Front-End Selectivity: Steep Tuning Frequency -45dB/Decade Roll-off +/-2kHz.<br /> Blocking Dynamic Range: 123dB at 20kHz Offset, 78dB at 2kHz Offset.<br /> CW Decoder, Direct/Iambic-A/B Keyer.<br /> VFO A/B+RIT and Sp<br /> CAT support (TS480 subset), you can stream audio, keystrokes and display text over CAT.<br /> This is probably the most cost-effective and easy to build standalone SDR/SSB transceiver. Greatly simplified the original QCX circuit (i.e., 50% fewer mounting components, no complicated transformer windings, no alignment procedures), and more versatile.<br /> Shell Material: ABS<br /> Product Size: Approx. 100.00x80.00x40.00mm<br /> Product Size: 3.94x3.15x1.57inch<br /> <br /> <p> <strong>Note:</strong><br /> Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!<br /> Please allow 1-2cm measuring deviation due to manual measurement. </p> <br /> &nbsp;<br /> </span> </div> <span><br /> </span> <div> <span><br /> </span> </div> <div style="padding:15px;border:1px solid #AEAEAE;"> <span> 1 x SDR QRP Transceiver&nbsp;<br /> 1 x Handheld Microphone<br /> &nbsp;<br /> </span> </div> <p> <span></span> </p> <p> <span><br /> </span> </p> <div style="text-align:center;"> <span></span> </div> <p> <span></span> </p> <p> <span><br /> </span> </p> <p> <span><br /> </span> </p> <p> <span><br /> </span> </p> <p> <span><br /> </span> </p> <p> <span><br /> </span> </p> </td> </tr> </tbody> </table></div></div>
