<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div class="desc"> <div style="width: px; line-height:150%; font-family:Arial, Helvetica, sans-serif; font-size:12px;"> <p style="margin-bottom:6px; margin-top:6px;"></p> <p> 1pc 8-Channel NPN/PNP to NPN 5V/24V SquareWave Signal Conversion Module Level Converter 10MHZ </p><div style="font:Arial;font-size:16px;"><p><b>Specification:</b></p>Description:<br/>This level converter is mainly used for PLC or MCU interface matching with other circuits, external circuit signal level conversion circuit,or other level conversion between control circuits.This module can convert 8-channel signals at the same time, using isolation chip of 10MHZ bandwidth, which can effectively guarantee speed and integrity of signal.<br/>Features: <br/>The module can convert input 5V level signal to 24V level signal, or convert input 24V level signal to 5V level signal. <br/>It can also convert signal 5V to 5V, or 24V to 24V level, and isolate input signal and output signal through optocoupler, which can improves anti-interference ability of circuit. <br/>Input level can be set by DIP switch, 24V level output is NPN OC output, output current is 100mA. <br/>It has conversion and amplification circuit, good wave, strong driving ability. <br/>Compatible with a common-cathode or common-anode input connection, matching European and Japanese PLC interface standards. <br/>Compatible with AC/DC input power supply interface, designed with power indicator light. <br/>When output is selected as 24V level, it is NPN OC output, with maximum 1A load capacity.24Voutput is OC output (NPN collector open circuit output), if you want to test output, it must add resistor, normally use a 10KR resistor. <br/>When converting signal to 24V level, the power supply of input should be 24V. <br/>When converting signal to 5V level, the power supply of input can be in between 7V-35V. <br/>You can use 4pcs M3 standoffs(not included) to install it.<br/>Specifications: <br/>Model: 8-5V24V-D <br/>Channel: 8-channel <br/>Input: NPN or PNP, 5V or 24V level squarewave signal <br/>Output: NPN 5V or 24V squarewave signal<br/>Size:Approx. 11 x 9 x 5cm/4.3 x 3.5 x 2in<br/>Weight: 170g(approx.) <br/>SwitchSW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8 <br/>Input 5V Level ON ON ON ON ON ON ON ON <br/>Input 24V Level OFF OFF OFF OFF OFF OFF OFF OFF <br/>Package Includes: <br/>1 x Level Converter<br/>Note:<br/>Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering.<br/><p><br/></p></div><br/> <p style="margin-bottom:6px; margin-top:6px;"> </p> <p><br/><br/><br/><br/><br/><br/><br/><br/><br/><br/><!--#list--><!--#if--></p><div style=" margin-bottom:6px; margin-top:6px;"> </div> <p class="STYLE1"><u>Shipping:</u></p> <p>1.We guarantee to ship goods out within 24-72 hour after payment confirmation except holiday.<br/> 2.We ship by China post,HKpost EMS,DHL,Fedex,according to your choice when placing orders .<br/> 3.If you didn't receive the item after 45 days,please feel free to contact us.We will make all our effort to resolve the problem.<br/> 4.We are not responsible for delays causedby the customs,Import duties,taxes or other customscharges.</p> <p class="STYLE1"><u>Warranty:</u></p> <p>1.All items have 1 year guarantee.IF your purchase do not meet merchantable quality, fitness for purpose or match the description, We can make sure your issues are resolved .<br/> 2.For wrongly-shipped items, Please contact us in 48 hours after delivery.We will arrange to deliver the correct items or return all your payment.<br/> 3.For defective or faulty products,please take photos or videos,we would resend or refund after confirmation. </p> <p style="margin-top:6px;"></p> </div></div></div></div>
