BMS 7S 29.4V 20A Li-ion Ternary Lithium 18650 Battery Charge Protection Board Balance Same Port Split Port Temperature Protect
<div class="detailmodule_dynamic"><kse:widget data-widget-type="relatedProduct" id="1005000004119628" title="" type="relation"></kse:widget></div>
<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><br />Features:<br />1. Single integrated circuit, stable and reliable: single high-performance integrated circuit design, significantly improve product stability and reliability, to ensure trouble-free operation for a long time<br />2. Short-circuit protection, safety: built-in high-efficiency short-circuit protection function, effectively preventing abnormal damage to the circuit, to protect the equipment and user safety.<br />3. Temperature protection, intelligent regulation: with accurate temperature monitoring and protection to avoid performance degradation or safety hazards caused by overheating.<br />4. Over-voltage and over-current protection, double guarantee: provide comprehensive over-voltage and over-current protection mechanism to ensure that the lithium battery can operate safely in various usage scenarios.<br />5. Charging and discharging protection, prolonging the life: support for charging and discharging bidirectional protection, optimize battery performance, effectively extend the life of lithium batteries</p>
<p>Parameter:<br />Charging protection<br />Single unit overcharge voltage: 4.25V±0.015V<br />Single overcharge recovery voltage: 4.15V±0.015V<br />Rated charging current: 7A<br />Charging protection temperature: -5~55℃<br />Discharge protection<br />Single over-discharge voltage: 2.5V±0.1V<br />Single over-discharge recovery voltage: 3.0V±0.1V<br />Rated discharge current: 20A<br />Peak discharge current: 80A<br />Discharge protection temperature: -20~75°C<br />Charge equalization current: No<br />Short-circuit protection: Yes; Recovery conditions: Charge recovery or load removal<br />Internal resistance: B-, P-conducting resistance ≤30mΩ<br />Self-dissipation current: ≤45uA<br />Size: 63.5*34*9.6mm<br />Cable length: 400mm<br />Operating Temperature: -40~80°C</p>
<p>Package include:<br />Module*1<br />Cable*1<br /></p></div></div>
$20.105
$10.145
- Category : Consumer Electronics
- Brand : diy_electronics_module_999_store DIY Electronics Module 999 Store
Colors
Sizes
-
+
<div class="detailmodule_dynamic"><kse:widget data-widget-type="relatedProduct" id="1005000004119628" title="" type="relation"></kse:widget></div>
<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><br />Features:<br />1. Single integrated circuit, stable and reliable: single high-performance integrated circuit design, significantly improve product stability and reliability, to ensure trouble-free operation for a long time<br />2. Short-circuit protection, safety: built-in high-efficiency short-circuit protection function, effectively preventing abnormal damage to the circuit, to protect the equipment and user safety.<br />3. Temperature protection, intelligent regulation: with accurate temperature monitoring and protection to avoid performance degradation or safety hazards caused by overheating.<br />4. Over-voltage and over-current protection, double guarantee: provide comprehensive over-voltage and over-current protection mechanism to ensure that the lithium battery can operate safely in various usage scenarios.<br />5. Charging and discharging protection, prolonging the life: support for charging and discharging bidirectional protection, optimize battery performance, effectively extend the life of lithium batteries</p>
<p>Parameter:<br />Charging protection<br />Single unit overcharge voltage: 4.25V±0.015V<br />Single overcharge recovery voltage: 4.15V±0.015V<br />Rated charging current: 7A<br />Charging protection temperature: -5~55℃<br />Discharge protection<br />Single over-discharge voltage: 2.5V±0.1V<br />Single over-discharge recovery voltage: 3.0V±0.1V<br />Rated discharge current: 20A<br />Peak discharge current: 80A<br />Discharge protection temperature: -20~75°C<br />Charge equalization current: No<br />Short-circuit protection: Yes; Recovery conditions: Charge recovery or load removal<br />Internal resistance: B-, P-conducting resistance ≤30mΩ<br />Self-dissipation current: ≤45uA<br />Size: 63.5*34*9.6mm<br />Cable length: 400mm<br />Operating Temperature: -40~80°C</p>
<p>Package include:<br />Module*1<br />Cable*1<br /></p></div></div>
