<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p>Features:<br/>1.Bidirectional charging and discharging with the same port: single interface realizes charging and discharging, simplifying the connection design<br/>2.LED status indicator: real-time monitoring of charging and working status, convenient for users to operate<br/>3.Stable high power output: rated 4A output current, peak 6A, to ensure stable operation of the equipment<br/>4.Intelligent charging protection: Built-in professional charging chip to ensure safe and efficient charging of the battery<br/>5.Comprehensive protection mechanism: with overload, short-circuit and battery over-discharge multiple protection functions</p><p>Parameter:<br/>Product Name: 2S/3S Charge Protection Module (UPS Power Module)<br/>Product Function: Charging + path + battery protection<br/>Input voltage: DC 12V/12.6V/15V, input current should be more than 6A, on-board indicator light<br/>2S version: input voltage DC 9V-10V, also can input 9V-15V<br/>3S Version: Input voltage DC 12V-12.6V, can also input 15V<br/>Output voltage: DC 6V/9V-12.6V<br/>Output current: rated 4A (about 50W), peak current 6A, recommended load below 4A<br/>Applicable batteries: support 2 or 3 series batteries<br/>No-load power consumption: 0.3-0.5mA/0.6-0.8mA<br/>Indicator light: Main board integrated LED indicator light<br/>External size: 50mm*20mm</p><p>Description:<br/>The product is the second version of the same port equal voltage uninterruptible power supply (UPS) control module, with bidirectional charging and discharging functions, built-in battery charging and protection mechanisms. It is suitable for network devices, intelligent devices and LED lights that support wide voltage.<br/>Product Version:<br/>2S version: connect to 7.4V-8.4V battery<br/>3S version: connect with 11.1V-12.6V battery</p><p>Package include:<br/>Module x1<br/></p></div></div><br/>
