<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p><span style="font-size: 16px; font-family: Verdana;">Input voltage: 36/48/60/72V</span></p><p><span style="font-size: 16px; font-family: Verdana;">Output voltage: 12V</span></p><p><span style="font-size: 16px; font-family: Verdana;">Output current: 10/15/20A</span></p><p><span style="font-size: 16px; font-family: Verdana;">Power:180W</span></p><p><span style="font-size: 16px; font-family: Verdana;">With short circuit, overcurrent, overvoltage protection and many other functions, to prevent damage during use.</span></p><p><span style="font-size: 16px; font-family: Verdana;">Wiring: Red --36/48 / 60/72(input - Battery +)</span></p><p><span style="font-size: 16px; font-family: Verdana;">Yellow --12V (output --LED +)</span></p><p><span style="font-size: 16px; font-family: Verdana;">Black - ground (sharing a common thread - Battery -)</span></p><p><span style="font-size: 16px; font-family: Verdana;">Wiring simplistic explanation: The red line converter connected to the battery\'s positive line, the yellow line converter connected devices: negative line (such as lights, speakers, stereo) the positive line, then the battery\'s negative cable and equipment are connected to the converter black lines (black lines so called common line) Please be careful not to pick the wrong line, wrong immediately burned, there is no second chance, oh.</span></p><p><span style="font-size: 16px; font-family: Verdana;">Third, the product Features:</span></p><p><span style="font-size: 16px; font-family: Verdana;">1. Temperature protection: limit the output when the temperature rises, to ensure reliable operation of the product within a suitable temperature range. Effectively extending the life of the product.</span></p><p><span style="font-size: 16px; font-family: Verdana;">2, short circuit protection: output short circuit, this product will not be damaged. Short-circuit protection. Most of the products currently on the market without short-circuit protection, low quality.</span></p><p><span style="font-size: 16px; font-family: Verdana;">3, can be loaded with low-voltage start, constant output.</span></p><p><span style="font-size: 16px; font-family: Verdana;">4, has a waterproof capability.</span></p><p><span style="font-size: 16px; font-family: Verdana;">Packing include:</span></p><p><span style="font-size: 16px; font-family: Verdana;">1*transformer</span></p></div></div> <div class="detailmodule_image"></div>
