<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p>Features:<br/>1. Single-board structure design: compact integrated structure, convenient installation, high stability, suitable for a variety of experimental environments<br/>2. Built-in signal generator: integrates sine wave, triangle wave and other waveform output functions to meet diversified testing needs.<br/>3. Waveform storage and recall: supports waveform saving and quick call-out function, which is convenient for comparative analysis and repeated use.<br/>4.500KHz high bandwidth: high-frequency response capability, accurately capture the details of complex signals.<br/>5. Ideal tool for electronic enthusiasts: easy to operate, powerful, a powerful assistant for learning electronic technology and exploring the world of circuits.</p><p>Parameter:<br/>Bandwidth: 500KHz <br/>ADC Accuracy: 12Bit <br/>Real-time Sampling Rate: 1.5Msps <br/>Waveform Buffer Length: 1024 points <br/>Vertical Sensitivity Range: 10mV/gram-5V/gram <br/>Input Impedance: 1MΩ <br/>Maximum Input Voltage: 50Vpk <br/>Coupling Mode: DC, AC, GND <br/>Horizontal Time Base Range: 1us/gram-500s/gram <br/>Trigger Mode: Auto, Conventional , Single <br/>Trigger Edge: 1us/gram-500s/gram <br/>Power Supply: DC 5V (via USB [Type C interface]) <br/>Current Consumption: &lt;100mA <br/>Product Dimensions: 118*76*12mm</p><p>Package include:<br/>DIY loose parts*1<br/><br/></p></div></div><br/>
