<div class="detailmodule_dynamic"><kse:widget data-widget-type="customText" id="1005000013403607" type="relation"></kse:widget></div><div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div><br/>Features:<br/>1. Wide voltage input DC6-24V, adapt to a variety of power supply environment<br/>2. High-efficiency conversion, efficiency up to 97%, reduce energy loss<br/>3. mini design, compact size, easy to integrate into a variety of equipment<br/>4. stable output, 5V16A, 12V12A, stable performance<br/>5. high reliability, built-in multiple protection circuits to ensure long-term stable operation</div><br/><p>Parameter:<br/>5V16A:<br/>Input voltage: DC6~24V<br/>Output voltage: DC5.1V ± 1%<br/>Rated output current: 16A<br/>Output ripple noise: &lt;20mV (1~16A load)<br/>Conversion efficiency: &gt;95% (input 12V, load current 1~16A)<br/>Static current (EN float): &lt;2mA<br/>Static current (EN ground): &lt;3uA<br/>12V12A:<br/>Input voltage: DC15~24V<br/>Output Voltage: DC12.1V±1%<br/>Rated output current: 12A<br/>Output ripple noise: &lt;50mV (1~12A load)<br/>Conversion efficiency: &gt;96% (input 24V, load current 1~12A)<br/>Static current (EN float): &lt;3mA<br/>Static current (EN ground): &lt;3uA<br/>Operating environment: -25℃~+70<br/>Output short circuit protection<br/>Over-temperature protection for the whole machine</p><p>Tips:<br/>1. Module set up on the back of the heat dissipation pad, heat dissipation pad is also GND, can be welded to a large area of copper pavement area to dissipate heat<br/>2. module input placed in the TVS tube, breakdown voltage of about 26V, this voltage is not the chip&#x27;s limit voltage, mainly used to absorb the input side of the abnormal voltage spikes, you can use 6S lithium battery input (25.2V)<br/>3. The chip has short circuit protection, peak current protection of about 25A</p><p>Package include:<br/>Buck Module *1<br/></p></div></div><br/>
