<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;"><strong></div></div> <div class="detailmodule_dynamic"><kse:widget data-widget-type="relatedProduct" id="1005000000650092" title="" type="relation"></kse:widget></div> <div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><br /><br />Product Introduction:</strong><br /></span><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">M430 is a voltage and current power measuring instrument, which can only measure and display the voltage, current and power of the circuit under test. It can be fine-tuned through the adjustable resistance. It does not have the function of voltage rise and fall or current limiting and regulating, so it does not affect the actual voltage and current of the circuit under test.</span><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">Do not use more than 30V high voltage work, otherwise the product will cause overvoltage damage.</span><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">10A range products come with shunt resistance, direct current measurement test end will appear short circuit, as long as according to the wiring diagram of the instrument in series after the load can be used normally.</span><br /><br /><strong><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">Operating voltage:<br /></span></strong><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">The operating voltage of the meter is 4 to 30V DC. 5 to 12V is recommended</span><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">The thin red line is the positive pole of the working power supply, the thin black line is the negative pole of the working power supply, and the thick black line belongs to the common ground</span><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">The maximum voltage connected to the thin red and black wires cannot exceed 30 V. It is recommended that 12V be supplied</span><br /><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;"><strong>Range of measurement:</strong><br /></span><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">Voltage measurement range 0~100V, 10V below display mode 0.00V, voltage 0.2V jump, error range &plusmn;1V,</span><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">The current measurement range is 0~10A, the current is 0.03A, the error is &plusmn;0.1A</span><br /><br /><strong><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">Package includes:<br /></span></strong><br /><span style="font-size: 16px; font-family: arial, helvetica, sans-serif; color: #000000;">Voltage&nbsp; X1</span><br /><br /></div></div>
