<div class="detailmodule_dynamic"><kse:widget data-widget-type="customText" id="1005000004074434" type="relation"></kse:widget></div><div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div><br/><span style="font-size:20px"><strong>Features:</strong></span><br/>1.This is an unfiltered Class AB amplifier with low quiescent current and low EMI, and FM mode without interference<br/>2.Stable product performance<br/>3.Widely used in Bluetooth speakers, lever speakers, USB speakers, etc<br/>4.Equipped with overheating protection, short circuit current protection, and undervoltage protection<br/>5.The product adopts high-quality materials and has a long service life</div><div><br/></div><p><span style="font-size:20px"><strong>Parameters:</strong></span><br/>Excellent blasting sound suppression circuit<br/>Low background noise, low distortion<br/>DRC dynamic distortion correction circuit<br/>10% THD+N, VDD=5V, providing up to 3W of output power under 4Q load<br/>10% THD+N, VDD=5V, providing up to 5W of output power under 20 loads<br/>Switching current&lt;0.5uA<br/>Multiple power packaging modes: ESOP-8 overheat protection<br/>Working voltage: DC2.5-5.5V<br/>Working current: above 1A<br/>Output power: 3-5 W<br/>3-5W horn<br/>Signal to noise ratio: 85dB @ VDD=5V, Vorms=1V</p><p><span style="font-size:20px"><strong>Package include:</strong></span><br/>Module X1<br/><br/></p></div></div><p><br/></p>
