<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"> <div class="detailmodule_dynamic"> <kse:widget data-widget-type="customText" id="1005000004997639" type="relation"></kse:widget> </div> <br /> <br /> Product Features<br /> Knob with start/stop function<br /> Slow start/stop time can be set<br /> Limit the upper and lower speed limit<br /> Frequency 1-100KHZ can be set<br /> Optional digital encoder knob Stable and durable High precision Better consistency<br /> Parameters can be set to power-down storage<br /> <br /> Product parameters<br /> Input voltage: DC6-60V (the specific voltage is equal to the rated voltage of the motor)<br /> Output voltage: linear under load<br /> Output current: 0-30A<br /> Continuous current: within 20A<br /> Speed regulation type: current regulation<br /> Speed regulation type: encoder knob 360 degrees<br /> Speed regulation range: 0-100%<br /> Setting frequency: 1-100KHZ can be set<br /> Slow start and stop: can be set<br /> Speed digital display: 0-100 percentage table<br /> Wiring type: fence type terminals<br /> Support motor: brush motor<br /> Module size: L*W*H 96mm*61mm*34mm<br /> Product net weight: 105g<br /> Panel opening: L*W 92mm*56mm<br /> Installation: Embedded<br /> <br /> Digital encoder knob operation:<br /> Short press--Switch motor start/stop<br /> Long press--Enter setting interface<br /> Clockwise--increase<br /> Counterclockwise--decrease<br /> Enter setting interface short press: switch function 1 function 2 function 3 function 4 function 5 function 6 long press save and exit<br /> Enter setting interface rotate: left turn to reduce the value, right turn to increase the value<br /> <br /> Slow start time setting Function 1: 000 - 100 Slow start to 100% speed time is adjustable between 0-10 seconds Default is 1 second.<br /> Slow stop time setting Function 2: 000 - 100 The slow stop time is adjustable between 0-10 seconds, default is 1 second.<br /> Lower Speed Limit Setting Function 3: 000 - 080 The minimum speed is adjustable from 0-80% and less than the maximum speed setting value.<br /> Upper Speed Setting Function 4: 000 - 100 The maximum speed is adjustable from 0-100% and is greater than the minimum speed setting value Default is 100%.<br /> Acceleration and deceleration value setting Function 5: 001 002 005 010 015 020 025 The speed changes 1%, 2%, 5%, 10%, 15%, 20%, 25% for each revolution.<br /> <br /> Frequency setting Function 6: Adjustable between 1-100KHZ Default 15KHZ.<br /> <br /> Note: The input voltage must be divided into positive and negative.<br /> The input voltage must be divided into positive and negative, not to mention 220V.<br /> The input voltage should be equal to the rated voltage of the motor within 6-60V.<br /> If the motor 12V input 12V motor 36V input 36V<br /> <br /> Slow start setting:<br /> Long press the knob for 3 seconds to enter setting function 1 Left turn to reduce the slow start time Right turn to increase the slow start time Long press the knob for 3 seconds to save and exit.<br /> Slow stop setting<br /> Long press the knob for 3 seconds to enter the setting interface Switch to function 2 by short press the knob Rotate the knob to adjust the size Long press the knob for 3 seconds to save the exit<br /> Lower speed limit setting<br /> Long press knob for 3 seconds to enter setting interface Switch to function 3 by short press knob Rotary knob to adjust size Long press knob for 3 seconds to save and exit<br /> Upper speed limit setting<br /> Press and hold the knob for 3 seconds to enter the setting interface Switch to function 4 by pressing the knob briefly Rotate the knob to adjust the size Press the knob for 3 seconds to save and exit<br /> Acceleration and deceleration value setting<br /> Press and hold knob for 3 seconds to enter setting interface Press and hold knob to switch to function 5 Rotary knob to adjust the size Press and hold knob for 3 seconds to save and exit.<br /> Frequency setting<br /> Press and hold the knob for 3 seconds to enter the setting interface Switch to function 6 by pressing the knob briefly Rotate the knob to adjust the size Press the knob for 3 seconds to save the exit<br /> <br /> Product List<br /> 1X Speed Controller<br /> <br /> <p>&nbsp;</p> </div></div>
