<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p>Features: <br />1. Based on ESP32-S3 MCU, integrated Wi Fi, Bluetooth, and Wi Fi HaLow triple network connection. <br />2. Long transmission distance, maximum speed of 32 Mbps, strong and stable signal. <br />3. Low power design, strong signal penetration, suitable for IoT applications in complex environments. <br />4. Supports integration of a 2-megapixel wide-angle camera and image processing and compression functions. <br />5. Equipped with an SD card slot, lithium battery management, and multiple protection measures, it is safe and convenient to use.</p> <p>Main features: <br />The MCU is ESP32-S3, and the Wi Fi HaLow module is HT-HC01. <br />Long transmission distance, up to 1-2km or more. <br />Fast transmission speed, up to 32 Mbps. <br />Low power design with strong penetration. <br />Integrated 300 pixel wide-angle camera. <br />Support Ard development environment. <br />Integrated SD card slot for easy local deployment and data storage. <br />Integrated CP2102 USB to serial chip for easy program download and debugging information printing. <br />The Type-C USB interface has complete protective measures such as voltage regulator, ESD protection, short circuit protection, and RF shielding. <br />Integrated Wi Fi, Bluetooth, and Wi Fi HaLow network connections, equipped with onboard 2.4 GHz patch antennas for Wi Fi and Bluetooth, as well as a reserved IPEX (U.FL) interface for Wi Fi HaLow. <br />Vehicle mounted SH1.25-2 battery interface, integrated lithium battery management system (charge and discharge management, overcharge protection, battery level detection, USB/battery level automatic switching).</p> <p>Product Introduction: <br />HT-HC33 is an integrated camera development board based on ESP32-S3 MCU and Wi Fi HaLow module. It is designed specifically for remote high-speed wireless communication. It supports transmission distances of over 1 kilometer and speeds of up to 32 Mbps, making it ideal for IoT applications that require reliable and high-performance connectivity. <br />This module adopts a low-power design and has excellent signal penetration capability, ensuring robust performance even in challenging environments. The integrated camera has a wide angle of 200 pixels and supports advanced image processing functions such as automatic exposure control, automatic gain control, image scaling, and image compression.</p> <p>Parameter： <br />Microcontroller: ESP32-S3R8 <br />Wi Fi HaLow module: HT-HC01 (MM6108Q) <br />Serial port chip: CP2102 <br />Wi-Fi HaLow：IEEE 802.11ah <br />Storage: 384KB ROM; 512KB SR; 16KB RTC SRAM; 8M PSRAM, 16MB SiP Flash <br />Interface: HaLow ANT (IPEX1.0); 2*15*1.27 Header Pins, 24P_0.5mm FFC connector(camera), USB TypeC, SH1.25-2 battery interface, Micro-SD card holder <br />Power Supply: 5V@USB , 2.7~4.2V @ battery <br />Working temperature: -30~+85 ℃ <br />Working humidity: 10% to 90%, non condensing <br />Size: 60.00 * 33.50 * 7.10mm (excluding camera) <br />application <br />Wi Fi HaLow can seamlessly integrate with traditional Wi Fi or Ethernet, making it suitable for most IoT scenarios, especially those that require long-distance high-speed transmission. <br />Smart Home and City <br />industrial automation control <br />Asset management and tracking <br />WiFi HaLow gateway and proximity sensor <br />Upgrading old device information <br />Wi Fi/Ethernet/Wi Fi HaLow extension and bridging <br />Rural Internet Access and LAN Construction <br />WiFi HaLow Device Development <br />Remote camera monitoring and network blind spot coverage <br />Digital transformation of legacy devices</p> <p>Package Include: <br />HT-HC33 development board x1 <br />cameras Module X1&nbsp;<br />2.54 * 13 rows of needles, X2 pieces <br />SH1.25 &times; 2 battery connector x1 <br />antennas X1<br /><br /></p></div></div>
