<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p></p><p><span style="font-size:14px"><strong>HaoHan FireF1y VTOL Vertical Takeoff and Landing Modular Multi-Mount FPV Patrol Drone Fixed-Wing FPV UAV Drone RC Airplane PNP/Semi</strong></span></p><p><br/></p><p><span style="font-size:14px"><strong>Specification:</strong></span><span style="font-size:14px"><br/>Model: FireF1y VTOL Vertical Takeoff and Landing Fixed-Wing FPV UAV PNP/SEMI<br/>Installation Time: &lt;1min<br/>Flight Speed: 10m/s-27.7m/s<br/>Cruising Speed: 15.8m/s<br/>Standard takeoff Weight: 1.5-1.8Kg<br/>Max takeoff weight: &lt;2Kg<br/>Maximum operating altitude: 4000m<br/>Wind Resistance Level: Level 5<br/>Remote Control Range: 15km (In open or spacious condition)<br/>Maximum endurance time: 50min(Full-Tab Battery 4S1P ) 90min(Full-Tab Battery 4S2P)<br/>Maximum range: 50km(Full-Tab Battery 4S1P) 90km(Full-Tab Battery 4S2P)<br/>Overall Dimensions: 1080×690×376mm<br/>EPP portable box Dimensions: 583×453×256mm</span></p><p><span style="font-size:14px">Motor 2216: 1100KV ESC: 30A PNP Empty Weight: 750g SEMI Empty Weight: 800g Propeller: 1×Carbon fiber Propeller EPP Case Dimensions: 583*453*265mm Package Dimensions: 600*500*280mm Servos: 4pcs 13g metal gear servo Recommended battery: 4S1P 21700 4S2P 21700</span></p><p><br/></p><p><span style="font-size:14px"><strong>Flight Controller Specifications:</strong></span><span style="font-size:14px"> MCU: 168MHz STM32F405RGT6 IMU: ICM42688-P (SPI) Barometer: DPS310 (I2C) OSD: AT7456E (SPI) Blackbox: MicroSD slot (SPI) 6x UARTs, 1x Softserial_Tx option (INAV/BF) 11 PWM outputs (8 Dshot compatible with BF/ArduPilot) 1x I2C 4x ADC (VBAT, current, RSSI, airspeed) 1 spare PINIO 3 XT30ESC power outputs Built-in inverter for SBUS input on UART2-RX</span></p><p><br/></p><p><span style="font-size:14px"><strong>PMU Specifications:</strong></span><span style="font-size:14px"> Input: 9-36V (3-8S battery) PDB: 3x 35A (maximum 3x 50A) BEC: 5V 1.5A BEC: 12V 2A LDO 3.3V: 200mA Current sensor: 220A, 3.3V analog-to-digital converter (INAV/BF scale 150,ArduPilot 66.7 A/V) Battery divider 1K:20K (INAV-2100, BF-210, ArduPilot BATT_VOLT_MULT 21.0) Dimensions: 33 x 55 x 19 millimeters Weight: 10g<br/><br/></span><span style="font-size:14px"><strong>Feature:</strong></span><span style="font-size:14px"><br/>- Effortless Vertical Takeoff and Landing: The FireF1y VTOL PNP/SEMI UAV simplifies aerial launch with its vertical takeoff and landing capability, providing flexibility for various environments.<br/>- Robust Wind Resistance: Engineered to withstand Level 5 wind conditions, ensuring stable and reliable flight even in challenging weather.<br/>- Quick and Easy Assembly: Modular quick-release design allows for set up in under a minute, perfect for on-the-go operations.<br/>- Multiple Flight Modes: Seamlessly switch between fixed-wing and multi-rotor modes, offering versatility for different missions.<br/>- Extended Flight Time and Range: Achieve up to 90 minutes of flight time and a maximum range of 90km with the Full-Tab Battery 4S2P, ideal for long-duration missions.<br/><br/></span><span style="font-size:14px"><strong>Package included:</strong></span><span style="font-size:14px"><br/></span><span style="font-size:14px"><strong>FireF1y VTOL PNP:</strong></span><span style="font-size:14px"><br/>1× FireF1y VTOL platform(3× motors, 3× 30A ESC, 3× propellers, 6xmetal gear servos)<br/>1x EPP portable case<br/>2× FireF1y nose sections<br/>1x Navigation light controller<br/>1x FPV transmission mounting fiberglass plate<br/>1× Thumb action camera mount<br/><br/></span><span style="font-size:14px"><strong>FireF1y VTOL SEMI:</strong></span><span style="font-size:14px"><br/>1× FireF1y VTOL platform(3× motors, 3× 30A ESC, 3× propellers, 6×metal gear servos)<br/>1x EPP portable case<br/>1× GPS<br/>1x Fully plug-and-play flight controller<br/>2× FireF1y nose sections<br/>1× Navigation light controller<br/>1x FPV transmission mounting fiberglass plate<br/>1× Thumb action camera mount</span></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p></p><p><br/><br/></p></div></div><p><br/></p>
