KKMOON CT 1.1 Counter Controller Module DC12V Counter Kit Module Circuit Board 0~999 Counting Range 1A 6V Direct Current
<p><kse:widget data-widget-type="customText" id="24886703" type="custom"></kse:widget></p><p><br/></p><div style="font-family:Arial, Helvetica, sans-serif;font-size:12px;line-height:150%"><p style="margin-bottom:6px;margin-top:6px"></p><p><strong>Features:</strong><br/>Counting range : 0~999, the counting value will be cleared after power off.<br/>When the count reaches the set value, the timer can be triggered to make the relay open or close for preset time.<br/>Timing Range: 0.1 seconds~ 999 minutes adjustable, relay can be closed first and then opened, it can be also opened first and then closed.<br/>A set of conversion (normally opened and normally closed).<br/>The pre-set parameters can be saved after power off.<br/><br/><strong>Specifications:</strong><br/>Operating Power: 12V<br/>Material: PCB<br/>Contact Load: 10A/277V AC or 10A/30V Direct Current <br/>Contact Resistance: ≤100mΩ (1A 6V Direct Current )<br/>Mechanical Durability: 10 millions <br/>Electricity Durability: >100,000 (10A-250VAC)<br/>Operating Temperature: -40~85℃<br/>Item Size: 50 * 40 * 20mm / 1.97 * 1.57 * 0.79in<br/>Item Weight: 27g / 0.95oz<br/>Package Weight: 30g / 1.06oz<br/>Package Size: 5 * 4 * 2cm / 1.97 * 1.57 * 0.79in<br/><br/><strong>Package List:</strong><br/>1 * Module<br/></p><p style="margin-bottom:6px;margin-top:6px"></p><p><br/><br/><br/><br/><br/><br/><br/></p><div style="margin-top:6px"></div><p style="margin-top:6px"></p></div><p><kse:widget data-widget-type="customText" id="34952974" type="custom"></kse:widget></p>
$35.45
$22.07
- Category : Tools
- Brand : tools_planet_store tools' planet Store
Colors
Sizes
-
+
<p><kse:widget data-widget-type="customText" id="24886703" type="custom"></kse:widget></p><p><br/></p><div style="font-family:Arial, Helvetica, sans-serif;font-size:12px;line-height:150%"><p style="margin-bottom:6px;margin-top:6px"></p><p><strong>Features:</strong><br/>Counting range : 0~999, the counting value will be cleared after power off.<br/>When the count reaches the set value, the timer can be triggered to make the relay open or close for preset time.<br/>Timing Range: 0.1 seconds~ 999 minutes adjustable, relay can be closed first and then opened, it can be also opened first and then closed.<br/>A set of conversion (normally opened and normally closed).<br/>The pre-set parameters can be saved after power off.<br/><br/><strong>Specifications:</strong><br/>Operating Power: 12V<br/>Material: PCB<br/>Contact Load: 10A/277V AC or 10A/30V Direct Current <br/>Contact Resistance: ≤100mΩ (1A 6V Direct Current )<br/>Mechanical Durability: 10 millions <br/>Electricity Durability: >100,000 (10A-250VAC)<br/>Operating Temperature: -40~85℃<br/>Item Size: 50 * 40 * 20mm / 1.97 * 1.57 * 0.79in<br/>Item Weight: 27g / 0.95oz<br/>Package Weight: 30g / 1.06oz<br/>Package Size: 5 * 4 * 2cm / 1.97 * 1.57 * 0.79in<br/><br/><strong>Package List:</strong><br/>1 * Module<br/></p><p style="margin-bottom:6px;margin-top:6px"></p><p><br/><br/><br/><br/><br/><br/><br/></p><div style="margin-top:6px"></div><p style="margin-top:6px"></p></div><p><kse:widget data-widget-type="customText" id="34952974" type="custom"></kse:widget></p>
