<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div class="desc"> <div style="width: px; line-height:150%; font-family:Arial, Helvetica, sans-serif; font-size:12px;"> <p style="margin-bottom:6px; margin-top:6px;"></p> <p> MAX038 Signal Generator DIY Kit 1Hz～20MHz Function Generator High-speed op-amp Generator Sine/Triangle/Rectangular/Sawtooth </p><div style="font:Arial;font-size:16px;"><p><b>Specification:</b></p>Features:<br/>Single power supply operation (built-in dedicated power management IC): single power supply operating voltage 9~15V.<br/>The circuit op amp works in dual power state (dual power supply amplification does not require a DC blocking capacitor to ensure high and low frequency signals are not distorted).<br/>It can output triangular wave, rectangular wave and sine wave, and forward and reverse sawtooth wave.<br/>Temperature drift of 200ppm/°C.<br/>SYNC output with sync signal.<br/>Switching the waveform output by push button, easy operation.<br/>Adopts with clear acrylic shell, the signal generator is very beautiful and practical.<br/>Specifications:<br/>Material: PCB+acrylic<br/>Frequency Adjustment Range: 1Hz～20MHz<br/>Duty Cycle Adjustment Range: 15%~85%<br/>Low Loss True Sine Wave: 0.75%<br/>Triangle Wave Output Linearity: 0.1%<br/>Low Impedance Output Buffer: 0.1Ω<br/>DC Offset Adjustable: -5V~5V<br/>Adjustable Output Amplitude: 0.1V~9.5VPP (operating voltage 9V)<br/>Item Size: 99 * 59 * 32mm / 3.90 * 2.32 * 1.26in<br/>Item Weight: 82g / 2.90oz<br/>Package Weight: 89g / 3.14oz<br/>Package Size: 12 * 9 * 4cm / 4.72 * 3.54 * 1.57in<br/>Package List:<br/>1 * Signal Generator<br/>1 * Manual (English)<br/>Note:<br/>The Signal Generator is a DIY Kit, need to assemble by yourself.<p><br/></p><p><b>Package List:</b></p>1 * Signal Generator<br/> 1 * Manual (English)<br/> <br/> <strong>Note:</strong><br/> The Signal Generator is a DIY Kit, need to assemble by yourself.</div><br/> <p style="margin-bottom:6px; margin-top:6px;"> </p> <p><br/><br/><br/><br/><br/><br/><br/><br/><br/><!--#list--><!--#if--></p><div style=" margin-bottom:6px; margin-top:6px;"> </div> <p class="STYLE1"><u>Shipping:</u></p> <p>1.We guarantee to ship goods out within 24-72 hour after payment confirmation except holiday.<br/> 2.We ship by China post,HKpost EMS,DHL,Fedex,according to your choice when placing orders .<br/> 3.If you didn't receive the item after 45 days,please feel free to contact us.We will make all our effort to resolve the problem.<br/> 4.We are not responsible for delays causedby the customs,Import duties,taxes or other customscharges.</p> <p class="STYLE1"><u>Warranty:</u></p> <p>1.All items have 1 year guarantee.IF your purchase do not meet merchantable quality, fitness for purpose or match the description, We can make sure your issues are resolved .<br/> 2.For wrongly-shipped items, Please contact us in 48 hours after delivery.We will arrange to deliver the correct items or return all your payment.<br/> 3.For defective or faulty products,please take photos or videos,we would resend or refund after confirmation. </p> <p style="margin-top:6px;"></p> </div></div></div></div>
