PD 65W Fast Charging Module PD2.0/3.0 QC2.0/3.0 PPS FCP AFC Quick Charger For Apple Huawei Samsung MTK Type-C DC 8-30V
<div class="detailmodule_dynamic"><kse:widget data-widget-type="customText" id="1005000004384065" type="relation"></kse:widget></div><div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div><br/><strong><span style="font-size:20px">Features:</span></strong><br/>1.Made of high quality materials, durable and practical<br/>2. Efficient and stable performance, the product comes with input over-voltage, under-voltage protection, output over-current, short-circuit protection, over-temperature protection and so on.<br/>3. Exquisite appearance, beautiful arrangement of components<br/>4. Compact size, easy to use, colorful LED lights show charging power.<br/>5. Application scenarios: vehicle charging transformation, car recorder power supply, switching power supply transformation and so on.</div><div><br/></div><p><strong><span style="font-size:20px">Parameter:</span></strong><br/>Input voltage: DC8~30V<br/>Output voltage: when access to TYPE-C compatible powered devices in the 3.3V ~ 21V automatically adjusted (input voltage should be higher than the output voltage, if you want to trigger 20V fast charging then the input voltage should be higher than 20V)<br/>Output power: Maximum 65W<br/>PD: 5V3A, 9V3A, 12V3A, 15V3A, 20V3.25A, 3.3~16V 3.25A, 3.3~21V 3A<br/>Conversion efficiency: 92%~97<br/>Output voltage ripple: <200mV<br/>No-load current: <3mA</p><p><strong><span style="font-size:20px">Supported fast charging protocols:</span></strong><br/>PD2.0/PD3.0 (PPS)<br/>Qualcomm QC2.0, QC3.0<br/>Huawei Fast Charging Protocol FCP<br/>Samsung Fast Charging Protocol AFC<br/>MTK PE<br/>BC1.2, Apple protocol</p><p><strong><span style="font-size:20px">Colorful LED lights show the power:</span></strong><br/>When not connected to the load, the indicator light is off, after accessing the load, the indicator light shows the corresponding color according to different power, from blue (5W) to purple (40W). When the power is less than 5W, the color of the indicator light is blue, and the lower the power, the lower the brightness. When the power is greater than 40W, the color of the indicator light remains purple.</p><p><strong><span style="font-size:20px">Package include:</span></strong><br/>Fast charging module *1<br/></p></div></div><p><br/></p>
$10.715
$5.75
- Category : Consumer Electronics
- Brand : diy_electronics_module_999_store DIY Electronics Module 999 Store
Colors
Sizes
-
+
<div class="detailmodule_dynamic"><kse:widget data-widget-type="customText" id="1005000004384065" type="relation"></kse:widget></div><div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div><br/><strong><span style="font-size:20px">Features:</span></strong><br/>1.Made of high quality materials, durable and practical<br/>2. Efficient and stable performance, the product comes with input over-voltage, under-voltage protection, output over-current, short-circuit protection, over-temperature protection and so on.<br/>3. Exquisite appearance, beautiful arrangement of components<br/>4. Compact size, easy to use, colorful LED lights show charging power.<br/>5. Application scenarios: vehicle charging transformation, car recorder power supply, switching power supply transformation and so on.</div><div><br/></div><p><strong><span style="font-size:20px">Parameter:</span></strong><br/>Input voltage: DC8~30V<br/>Output voltage: when access to TYPE-C compatible powered devices in the 3.3V ~ 21V automatically adjusted (input voltage should be higher than the output voltage, if you want to trigger 20V fast charging then the input voltage should be higher than 20V)<br/>Output power: Maximum 65W<br/>PD: 5V3A, 9V3A, 12V3A, 15V3A, 20V3.25A, 3.3~16V 3.25A, 3.3~21V 3A<br/>Conversion efficiency: 92%~97<br/>Output voltage ripple: <200mV<br/>No-load current: <3mA</p><p><strong><span style="font-size:20px">Supported fast charging protocols:</span></strong><br/>PD2.0/PD3.0 (PPS)<br/>Qualcomm QC2.0, QC3.0<br/>Huawei Fast Charging Protocol FCP<br/>Samsung Fast Charging Protocol AFC<br/>MTK PE<br/>BC1.2, Apple protocol</p><p><strong><span style="font-size:20px">Colorful LED lights show the power:</span></strong><br/>When not connected to the load, the indicator light is off, after accessing the load, the indicator light shows the corresponding color according to different power, from blue (5W) to purple (40W). When the power is less than 5W, the color of the indicator light is blue, and the lower the power, the lower the brightness. When the power is greater than 40W, the color of the indicator light remains purple.</p><p><strong><span style="font-size:20px">Package include:</span></strong><br/>Fast charging module *1<br/></p></div></div><p><br/></p>
