<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><p>Features:<br/>1.48 channels covering multiple bands, accurate frequency switching, stable signal without interference<br/>2.Support 5.8GHz band, professional wireless transmission, suitable for high performance quadcopter<br/>3.Power failure memory function, automatically restore the last used frequency band and channel, worry-free use<br/>4.Independent audio/video output, support two output signals to meet diversified needs<br/>5.High sensitivity reception, -95dBm to ensure clear transmission over long distances and excellent picture quality</p><p>Parameter:<br/>Product Name: RC-HD Wireless Audio/Video Receiver<br/>Receiving frequency: ISM 5645-5945MHz<br/>Available channels: 48 channels<br/>Sensitivity: -95dBm<br/>Operating voltage: DC 7-24V<br/>Current consumption: 200mA(Max)<br/>Antenna Input Impedance: 50ohm Typ<br/>Antenna Connector: SMA<br/>Antenna Gain: 2dBi<br/>Video Output Level: 1.0Vp-p Typ, 75Ω<br/>Audio Output Level: 1.0Vp-p Typ, 10KΩ<br/>Audio Carrier: 6.5MHz<br/>Type Standard: NTSC/PAL<br/>Note: The channel before power failure is automatically selected after re-powering on the unit</p><p>Description:<br/>1. 48 channels: Covering A, B, E, F, R bands and L band (airwave band), 6 bands, all frequencies can be compressed.<br/>2. Two switch buttons: CH button for frequency channel switching, FR button for frequency band switching.<br/>3. Two-digit display: one for CH, the other for FR, which can be used to locate which band and channel are received in real time.<br/>4. Power failure memory: replay the last band and channel.<br/>5. Independent video and audio signal output</p><p>Package include:<br/>Receiver x1<br/>Antenna x1<br/>Power cord x1<br/>Audio/video cable x1<br/><br/></p></div></div><br/>
