<div class="detailmodule_dynamic"><kse:widget data-widget-type="relatedProduct" id="1005000004103227" title="" type="relation"></kse:widget></div> <div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><br />Features:<br />1.48 channels covering multiple bands, accurate frequency switching, stable signal without interference<br />2.Support 5.8GHz band, professional wireless transmission, suitable for high performance quadcopter<br />3.Power failure memory function, automatically restore the last used frequency band and channel, worry-free use<br />4.Independent audio/video output, support two output signals to meet diversified needs<br />5.High sensitivity reception, -95dBm to ensure clear transmission over long distances and excellent picture quality</p> <p>Parameter:<br />Product Name: RC-HD Wireless Audio/Video Receiver<br />Receiving frequency: ISM 5645-5945MHz<br />Available channels: 48 channels<br />Sensitivity: -95dBm<br />Operating voltage: DC 7-24V<br />Current consumption: 200mA(Max)<br />Antenna Input Impedance: 50ohm Typ<br />Antenna Connector: SMA<br />Antenna Gain: 2dBi<br />Video Output Level: 1.0Vp-p Typ, 75&Omega;<br />Audio Output Level: 1.0Vp-p Typ, 10K&Omega;<br />Audio Carrier: 6.5MHz<br />Type Standard: NTSC/PAL<br />Note: The channel before power failure is automatically selected after re-powering on the unit</p> <p>Description:<br />1. 48 channels: Covering A, B, E, F, R bands and L band (airwave band), 6 bands, all frequencies can be compressed.<br />2. Two switch buttons: CH button for frequency channel switching, FR button for frequency band switching.<br />3. Two-digit display: one for CH, the other for FR, which can be used to locate which band and channel are received in real time.<br />4. Power failure memory: replay the last band and channel.<br />5. Independent video and audio signal output</p> <p>Package include:<br />Receiver x1<br />Antenna x1<br />Power cord x1<br />Audio/video cable x1<br /></p></div></div>
