<div class="detailmodule_dynamic"><kse:widget data-widget-type="relatedProduct" id="1005000004114844" title="" type="relation"></kse:widget></div> <div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><br />Product features:<br /><br />1. Multi channel analysis capability: This logic analyzer is equipped with 8 input channels, which can simultaneously capture and analyze multiple digital signals, suitable for complex digital circuit debugging and analysis.<br /><br />2. High sampling rate: Usually provides a high sampling rate, allowing users to accurately capture rapidly changing digital signals, which is particularly important for high-frequency signal analysis.<br /><br />3. Powerful triggering function: With flexible triggering settings, users can define triggering conditions as needed, such as edge triggering, pulse width triggering, etc., in order to capture events of interest.<br /><br />4. Software support and visual interface: Paired with user-friendly PC software, it provides functions such as waveform display, protocol analysis, and data analysis, making data interpretation intuitive and convenient.<br /><br />5. Portable and plug and play: Compact design, easy to carry; At the same time, it supports USB interface connection to computers, plug and play, no additional configuration required, suitable for on-site debugging and teaching demonstrations.<br /><br />6. Wide application scope: Suitable for various scenarios such as embedded system development, I2C/SPI/UART bus protocol analysis, digital circuit fault diagnosis, etc.<br /><br />7. Cost effectiveness: As a product of Sipeed, SLogic Combo 8 is often known for its cost-effectiveness, providing powerful tools for budget sensitive developers and educational institutions.<br /><br /><br /><br />Product Introduction:<br /><br />SLogic Combo 8 is a development tool that combines the functions of a logic analyzer, CKLink debugger, DAP Link debugger, and USB2ART. Users can switch between functions by pressing buttons, and select functions by pressing buttons and observing indicator colors.<br /><br />As a logic analyzer, it supports a maximum sampling rate of 80MHz and can be used in conjunction with an upper computer to parse the majority of protocols; As a UART module, it supports 4 serial ports simultaneously and a maximum baud rate of 20M, which can adapt to most scenarios where serial ports are used; When used as CKLink or DAPLink, it can be used to debug RISC-V series chips, ARM series chips, and additionally supports 1 serial port for observing logs.<br /><br /><br /><br />Product parameters:<br /><br />SLogic functional parameters:<br /><br />Logic analyzer: SLogic Combo 8<br /><br />Maximum number of channels: 8CH<br /><br />Maximum sampling rate: 80M<br /><br />Transmission bandwidth: 320Mb/s<br /><br />Sampling mode: Stream<br /><br />Typical configuration: 80M@4CH 40M@8CH<br /><br />Signal input range: 0-3.6V<br /><br />High and low level threshold: VIH&gt;2V VIL&lt;0.8V<br /><br />Note: The maximum transmission bandwidth of SLogic Combo 8 in Windows environment is 160Mb/s, typical configuration 80M@2CH 40M@4CH<br /><br /><br /><br />CKLink functional parameters:<br /><br />CKLink：SLogic Combo 8<br /><br />JTAG clock rate: 16M<br /><br />Typical dump speed: 1200KB/s<br /><br />Debugging serial port: up to 20Mbps<br /><br /><br /><br />DAPLink function parameters:<br /><br />DAPLink：SLogic Combo 8<br /><br />Debugging serial port: up to 20Mbps<br /><br />Typical burning speed: 110KB/s<br /><br /><br /><br />UART function parameters:<br /><br />High speed quad port: SLogic Combo 8<br /><br />Maximum baud rate: 2x20Mbps+2x1Mbps<br /><br />Total bandwidth: 42Mbps<br /><br /><br /><br />Main body size: approximately 4.1 * 2.1 * 1cm<br /><br /><br /><br />Product List:<br /><br />1X Logic Analyzer<br /><br />1X Accessories<br /></p></div></div>
