<p>Designed to be used as the interface antenna connection for portable terminal devices as well as circuit testing on microwave boards (DC to 10 GHz) the coaxial switch offers high performance, low loss, extremely high durability and reliability, in a small and lightweight package.</p><p>Features: Low insertion loss, wireless communication modules (Bluetooth, WLAN, UWB, ZigBee), portable terminals, notebook computers, ETC, POS terminals, GPS terminals, PDA, and any small devices requiring verification of antenna/circuit performance and re-direction of the transmission.</p><p>Product Specifications: Operating Temperature Range: -40°C ~ 85°C, Rated Power: 4W, Frequency Range: DC to 10GHz, Contact Resistance: 100mΩ max. @ 100mA, Insulation Resistance: 1000MΩ min. @ 100VDC, Withstanding Voltage: No l ashover or insulation breakdown @ 100VAC/ 1 minute</p><p>Material Specifications: Shell: Brass; Gold Plated, Insulators: Polyamide; UL94V-0, Common Terminal: Beryllium Copper; partially gold plated (Nickel barrier), Antenna Terminal: Phosphor Bronze; partially gold plated (Nickel barrier)</p>
