<div class="detailmodule_dynamic"><kse:widget data-widget-type="customText" id="1005000004074434" type="relation"></kse:widget></div><div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div><br/><strong><span style="font-size:20px">Features:</span></strong><br/>1. Adopting high-power digital power amplifier dedicated inductors, high current, low magnetic loss, low heat generation, and using oxygen free copper wires to improve sound quality; The magnetic shielding mechanism is resistant to electromagnetic interference.<br/>2.QCC3034 Qualcomm module, supporting transmission encoding SBC, AAC, APTX, APTX-LL, APTX-HD.<br/>3. QCC3034+PCM5102A, lossless transmission, lossless decoding, no loss, perfectly displaying the dynamics and details of sound, without burrs at high frequencies, rounded at mid tones, powerful at low frequencies, and good elasticity.<br/>4. Extremely high parameter performance: dynamic 112dB, signal-to-noise ratio 112dB, distortion level -93dB.<br/>5. Equipped with protection mechanism, input undervoltage, input anti reverse connection, overheating, overcurrent, and short circuit protection.</div><br/><p><strong><span style="font-size:20px">Parameter:</span></strong><br/>Product name: 2.1 channel Qualcomm BT amplifier board 100W+100W+200W<br/>Product model: ZK-APTX1<br/>Adapted power supply: The working voltage range is 12-30VDC, and it is recommended to use a DC power supply with a voltage of 24V-28V and a current of 10A or above.<br/>Maximum power: left or right channel—— 105W@30V , 4 Ω; 55W@30V , 8 Ω. Subwoofer—— 208W@30V 2 Ω; 105W@30V , 4 Ω. In short, the higher the voltage, the smaller the resistance, and the greater the output power.<br/>Adapted speakers: left and right channels, supporting speakers up to 3-8 ohms and 100W; The subwoofer supports 2-8 ohms and speakers up to 200W.<br/>BT chip: QCC3034, transmission distance of 15 meters.<br/>Input method: Bluetooth+AUX, BT priority, Bluetooth needs to be disconnected when using audio cable input.<br/>Number of channels: 2.1, left and right channels+subwoofer<br/>Power amplifier chip: Two TI original TPA3221<br/>Protection mechanism: Input undervoltage, input anti reverse connection, overheating, overcurrent, short circuit protection.<br/>Product size: 118x100x25mm</p><p><strong><span style="font-size:20px">Package include: </span></strong><br/>Installing an external antenna (special scenario):<br/>1. The boards are equipped with onboard antennas, with a normal distance of 10-15 meters. If they are installed in a metal shell (which will block the signal) or increase the Bluetooth distance (20-30 meters), external antennas will be used.<br/>2. Customers are required to purchase 2.4G antennas (antenna extension cables, antenna rods) on their own, and this product does not include external antennas.</p><p><strong><span style="font-size:20px">Product List:</span></strong><br/>Set 1:<br/>APTX1 amplifier board * 1</p><p>Set 2:<br/>APTX1 amplifier board * 1<br/>Shell * 1</p><p>Set Three:<br/>APTX1 amplifier board * 1<br/>Lead wire * 5<br/></p></div></div><br/>
